The Graco 25D345 LineLazer V 250SPS HP Reflective Series is a self-propelled, hydraulic airless line striper engineered for maximum productivity, precision, and reflective striping performance on large-scale jobs. Designed for contractors working on parking lots, roadways, and municipal projects, this unit combines automatic striping, powered drive, and integrated bead application for unmatched efficiency.
Featuring dual automatic guns and push-button striping, operators can produce consistent lines and skip patterns with minimal effort. The pressurized EZ Bead System with a 120 lb bead tank ensures proper bead flow and optimal paint penetration for durable, high-visibility markings.
This model includes the LazerGuide 3000 long-line laser system, delivering enhanced accuracy for long-distance striping and improved line straightness. Powered by a Honda GX390 engine and supported by a high-efficiency hydraulic system, the 250SPS HP Reflective provides no-stall operation, extended runtime, and reduced operator fatigue—making it ideal for high-production, professional striping contractors.
- Pressurized EZ Bead System
- Superior Bead Application Performance
- Ensures proper bead flow and paint penetration
- Dual bead tanks hold up to 120 lbs each
- Automatic Paint Gun System
- Automatically Stripe Skip-Lines
- Reduce operator fatigue — push button line production
- Quality solenoid driven system
- LazerGuide 3000 Long-Line Lazer
- Easier, laser-straight lines
- Longer distance accuracy
- Highly-visible laser guise
- Faster, simple operation
- Remote Mount Control Box
- Striping Information At-A-Glance
- Simple to use and easy to see in all conditions
- 25-Gallon Paint Hopper
- Less Refilling
- Extended striping time with large capacity hopper
- Honda® GX Engine
- Reliable, Easy-to-Start Power
- Contractor-preferred — excellent power and proven reliability
- Oil Alert shuts down engine to prevent damage if oil level drops too low
- Electric Start
- Fast starting
- EasyMark Gun Adjustment System
- Easy Gun Adjustments
- Perfect gun alignment every time with easy-to-use guide mark system
- 2-gun capability with QuikSelect gun selector
- Front or Rear Gun Mount
- Straighter long lines
- Use up to six guns
- Additional Features
- Self-Centering Front Wheel
- Easy Handlebar Adjustment
- Endurance Chromex Pump
- High-Efficiency Hydraulic Motor
- High-Capacity Cooling System
- Easy Out Pump Filter
Machine Specifications
| Specification | Details |
| Brand | Graco |
| Model | LineLazer V 250SPS HP Reflective (Self-Propelled) |
| Part Number | 25D345 |
| Power Source | Gas (Hydraulic Drive) |
| Engine Power | 13 HP |
| Engine | Honda GX390 |
| Maximum Operating Speed | 10 mph |
| Maximum Working Pressure | 3300 PSI |
| Maximum Flow Rate | 9.46 L/Min |
| Maximum Tip Size | 0.055 in |
| Number of Colors | 1 |
| Number of Pumps | 1 |
| Number of Hoppers | 1 |
| Hopper Capacity | 25 Gallons |
| Bead System | Pressurized EZ Bead System |
| Bead Tank Capacity | 120 lb |
| Number of Guns | 2 (Automatic) |
| Weight | 776 lbs |
Operational Details
UPC: 755652690542
Country of Origin: United States
Unit of Measure: Each
Included Components
LazerGuide 3000 Long-Line Laser
Pressurized Bead System (1 Tank)
Flex Plus Spray Guns (2)
RAC 5 321 Spray Tips (2)
RAC 5 425 Spray Tips (2)
RAC 5 627 Spray Tips (2)
RAC 5 Tip Guards (2)
3/8" x 12 ft BlueMax II Hose
3/8" x 3 ft Whip Hose
TSL (4 oz)
Recommended Applications
Long-line roadway striping
Airport and runway striping
Municipal and DOT striping
Large parking lot striping
High-precision, high-production striping jobs
Reflective striping applications
