Cat Pumps 290 3 Frame Piston Pump, 1200 psi at 3.5 GPM

Cat Pumps 290 3 Frame Piston Pump, 1200 psi at 3.5 GPM

This triplex (three piston rods) positive displacement, reciprocating piston pump is constructed with chrome-plated brass manifolds, 304 stainless steel valve assemblies, and chrome-plated 304 stainless steel sleeves and cylinders. Multiple piston cup and seal configurations are available with NBR (Buna-N) O-rings.

The lower RPM belt drive design provides strong inlet suction and long-lasting pump and seal life.

Features

• Triplex Uniflow design provides continuous forward liquid flow,promoting smooth operation.
• Wetted cups and floating pistons are lubricated and cooled by pumped liquid, resulting in longer cup life.
• Mechanically-actuated inlet valves create strong lift and an easier prime.
• Optional 316 stainless steel manifolds provide added corrosion resistance.
• Pump comes standard with NBR seals. Alternative seal materials are available for higher temperature or chemical compatibility

Technical Specifications

• Max Flow: 3.5 gpm / 13.2 lpm
• Max Pressure: 1200
• Inlet Port Size: 1/2" NPT(F)
• Discharge Port Size: 3/8" NPT(F)
• RPM: 1200
• Drive Type(s): Belt, Clutch
• Material: Brass
