General Pump CW2040 CW Series Pump – 5 GPM, 1500 PSI | Summary
The General Pump CW2040 is a rugged, high-performance triplex plunger pump designed specifically for the demanding requirements of self-serve car wash applications. Delivering 5 GPM at 1500 PSI at a max speed of 1250 RPM, this pump thrives in high-temperature and chemical-intensive environments.
Built with a forged brass manifold backed by a lifetime warranty, anodized die-cast aluminum crankcase, solid ceramic plungers, and a dual-shaft design, the CW2040 is favored by professionals looking for maximum durability, longevity, and serviceability.
General Pump CW2040 – CW Series Car Wash Triplex Pump | Features
-
Dual-shaft crank design: Ideal for flexible mounting and easy integration
-
Lifetime-warranty forged brass manifold: Corrosion-resistant and durable
-
Oversized connecting rods: Enhance pump longevity under heavy loads
-
Die-cast anodized aluminum crankcase: With large oil bath for better cooling
-
Solid ceramic plungers: With continuously lubricated packings
-
Heavy-duty tapered roller bearings
-
Stainless steel inlet and discharge valves
-
Rated for high-temperature and chemical duty cycles
-
Backed by a 5-year warranty from General Pump
| Specification | Details |
| Brand | General Pump |
| Part Number | CW2040 |
| Max Flow | 5.0 GPM |
| Max Pressure | 1500 PSI |
| RPM | 1250 |
| Bore / Stroke | 20mm / 16mm |
| Oil Capacity | 33.8 oz |
| Inlet Port | 1/2" - 14 BSPP-F |
| Discharge Port | 3/8" - 19 BSPP-F |
